Located in St. Petersburg FL (KSPG)
Click picture of bag to see Logs
Cirrus build sheet serial number 2370
ITEM DRAWING NO.: DASH NOMENCLATURE
1 11000 -007 Aircraft Complete, Model SR20
2 37741 -002 Installation, Powerplant, IO-390-C3B6, Hot Weather
3 38372 -002 Propeller Installation, Composite
4 38450 -001 Fuselage Electrical
5 38410 -001 Engine Instruments
6 25511 -012 Ice Light Option
7 34926 -002 406MHz ELT Installation
8 38405 -001 Flight Display 12"
9 38411 -002 Installation, Flight Stream 510
10 25520 -002 Enhanced Vision
11 38425 -001 Transponder Mode S w/ UAT
12 38415 -021 Exterior Lighting Installation SR20
13 38409 -001 Interior Lighting Installation w/ Convenience
14 25507 -002 CO Detector
15 25519 -001 Synthetic Vision Option Unlock
16 25519 -002 Chartview Option Unlock
17 25519 -003 TAWS Option Unlock
18 25519 -005 Surfacewatch Unlock
19 38420 -001 Data Link Installation XM
20 - - (No Stormscope)
21 25617 -020 Air Conditioning Option
22 38408 -001 Autopilot GFC 700
23 25519 -004 ESP Option Unlock
24 25514 -002 DME Installation GFC 700 (No DME)
25 25509 -002 Traffic System Garmin GTS 800
26 38430 -011 Avionics Dual ADAHRS, Non-FIKI
27 38407 -002 Standby Instruments, Digital Dual ADAHRS
28 18202 -006 Step-Handle Installation, Black
29 11952 -003 Window Installation, Tinted, UV
30 31040 -001 Assembly and Installation, Cowl
31 25538 -001 Fuselage, Common, A/C, Rear Bench Seat
32 25536 -003 Cabin Air Installation, Air Conditioning
33 28896 -005 Wing Installation (No ice protection)
34 18631 -008 Installation, Nose Landing Gear, w/ Pant Fairings
35 26960 -002 Installation, Fairings, NLG
36 19890 -003 Fairings, Main Landing Gear, LH
37 19890 -004 Fairings, Main Landing Gear, RH
38 18820 -001 Aft Tie Down/Ballast 0.0 LB (Original)
39 37863 -003 Interior Panels, Rear Bench Seat MY2016, Carbon/Platinum/Rhodium
40 37887 -008 Installation, Seats and Stitch, MY2016 MY2016, Carbon Lunar Grey
41 28243 -007 Instrument Panel W / Inlay
42 38311 -003 Installation, Placard and Decal, Interior SR20 Carbon Pattern
43 23138 -005 Interior Lighting Installation, Standard
44 22114 -001 Installation, Panel Ducting, Standard
45 29405 -002 Installation, Seat Belts, Rear Bench Rear Seat
46 - - (Not OSS)
47 37747 -003 Installation, Engine Pre-Heater, 115 Volt
48 - - (US Registry)
49 - - (US Registry)
COMMENTS:
Paint: CARBOND WHITE AND STERLING
Stripe: CARBON
2017 SR20 GTS Carbon
GTS
The GTS is truly the SR20 flagship. Combine all the packages for even greater value: Cirrus Select; Alerts, Awareness & Assistance; Digital Advantage; Prestige, Comfort & Convenience; Carbon/Platinum/Rhodium Upgrade plus Active Traffic Information and authentic GTS badging. GTS is the luxury, technology and performance standard by which all other aircraft are measured. GTS Weight: 2146 lbs.
ADDITIONAL OPTIONS
CIRRUS SELECT
Cirrus Select adds the Enhanced Vision System (EVS) displayed on big 12” screens and eTAWS2 . EVS creates an image of what is outside the aircraft by using infrared technology to turn night into day. eTAWS is a TAWS-B terrain warning system with greater predictive precision information based on your flight path, and if terrain is ahead, gives you early warning aural alerts. Weight Δ: 5 lbs.
ALERTS, AWARENESS & ASSISTANCE
Fly with increased precision and awareness with Synthetic Vision Technology (SVT™). SVT gives you the digital version of the world portrayed on your PFD with numerous navigation and obstruction aids to increase your flight security. Know where you are on approach or on the airport itself with ChartView (Jeppesen published electronic charts) and one year of navigation data subscriptions. SurfaceWatch™2 monitors your aircraft’s position on the ground providing enhanced situational awareness through aural and visual alerts to the pilot throughout the airport terminal environment.
DIGITAL ADVANTAGE
Upgrade your Cirrus to a truly all-digital cockpit with the Digital 4-in-1 Standby Instrument. The Garmin Flight Stream 510 allows you to connect your mobile device to the Cirrus Perspective panel1 . SiriusXM Weather and Audio2 receiver completes the ultimate GA Cockpit. Weight Δ: 6 lbs.
PRESTIGE, COMFORT & CONVENIENCE
CARBON APPEARANCE UPGRADE
Inspired by the unmistakable style of the most legendary sports cars, the Carbon Appearance premium upgrade utilizes a new palette of accent colors that delivers a stunning tarmac presence. Interior details such as jet black vents, carbon fiber instrument panel lobes and two-tone premium leather bolstered seats complete this exhilarating look.
AIR CONDITIONING Stay cool with this factory installed Air Conditioning System. Weight ∆: 55 lbs.
ACTIVE TRAFFIC INFORMATION
Always know where other aircraft are located with alerts from all aircraft with an active transponder within your proximity. Weight ∆: 15 lbs
HARTZELL LIGHTWEIGHT CARBON COMPOSITE PROP
Significantly increase your SR20’s useful load and add ramp presence with the three-blade composite propeller
TANIS ENGINE PRE-HEATER
Cirrus owners already have an unparalleled appreciation for quality and performance. It’s the reason Cirrus continues to be the world’s bestselling airplane in its class. Now, Xi takes this one step further through individualization - by making you an integral part of the design team for your dream airplane. A unique experience worthy of every flight you will make in your Cirrus, you will develop a personal working relationship with the Xi Team, working one-on-one to tailor your plane to your exact specifications and preferences for materials, colors, designs and more. With Xi, you define the art of the possible.
Xi COMPLETE
